YSLY-CY-JZ
(Other names: FLEX-CY-JZ, ÖPVC-JZ-YCY, สายคอนโทรล-มีชีลด์-PVC 2 ชั้น-เปลือกนอกใส)
Flexible control cable, PVC insulated, with inner sheath, Cu screen and external PVC sheath
Application
Flexible control cable used for signaling and control of static or mobile devices in industry, electric plants or offices.
Screen of braided copper wires serves as protection against electromagnetic impacts and control disturbances.
Resistant to medium mechanical loads, used for fixed or limitedly mobile installations (not permanently mobile) without tensile load.
Installed in dry or damp premises, outdoor application only under protection against UV-irradiation. Not intended for laying in ground or water.
Flexible control cable used for signaling and control of static or mobile devices in industry, electric plants or offices.
Screen of braided copper wires serves as protection against electromagnetic impacts and control disturbances.
Resistant to medium mechanical loads, used for fixed or limitedly mobile installations (not permanently mobile) without tensile load.
Installed in dry or damp premises, outdoor application only under protection against UV-irradiation. Not intended for laying in ground or water.
Construction
1. Conductor: Bare copper conductor, fine wired stranded, class 5 acc. to IEC 60228 / HD 383 / DIN VDE 0295
2. Insulation: PVC compound TI2 acc. to EN 50363 / DIN VDE 0281 or YI2 acc. to VDE 0207.4
4. Screen: Braid of tinned copper wires of 0.16 mm diameter, with min. 75% coverage
5. External sheath: PVC compound TM2 acc. to EN 50363 / DIN VDE 0281 or YM2 acc. to VDE 0207.5
1. Conductor: Bare copper conductor, fine wired stranded, class 5 acc. to IEC 60228 / HD 383 / DIN VDE 0295
2. Insulation: PVC compound TI2 acc. to EN 50363 / DIN VDE 0281 or YI2 acc. to VDE 0207.4
- • With Green/Yellow core, always in external layer (≥3 cores) or without Green/Yellow core
- • Core marking: (Acc. to DIN VDE 0293) Black numbered or colored
- • Cores stranded in layers
4. Screen: Braid of tinned copper wires of 0.16 mm diameter, with min. 75% coverage
5. External sheath: PVC compound TM2 acc. to EN 50363 / DIN VDE 0281 or YM2 acc. to VDE 0207.5
- • Sheath color: Grey (RAL 7001) or Transparent
Technical data
Temperature range:
Test voltage: Min. 4000 V
Insulation resistance: Min. 20 MΩ x km
Minimal inner bending radius: (D = external cable diameter)
Temperature range:
- • During installation and application with bending: -5 °C up to +50 °C
- • Fixed installed: -30 °C up to +70 °C
Test voltage: Min. 4000 V
Insulation resistance: Min. 20 MΩ x km
Minimal inner bending radius: (D = external cable diameter)
- • Fixed installed: 6D
- • At application with bending: 20D
CPR
Construction Products Regulation: Cable for general use in construction in accordance with fire protection regulations.
Harmonized standards: EN 50575:2014 i EN 50575:2014/A1:2016
Reaction to fire: Eca
Dangerous substances: N.P.D.
Construction Products Regulation: Cable for general use in construction in accordance with fire protection regulations.
Harmonized standards: EN 50575:2014 i EN 50575:2014/A1:2016
Reaction to fire: Eca
Dangerous substances: N.P.D.
Dimensions (Available in stock)
| Cable Type | Dimensions | Nominal Voltage | Packing |
|---|---|---|---|
| YSLY-CY-JZ | 4 x 0.75 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 1.5 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 2.5 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 4 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 6 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 10 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 16 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 25 | Cut-to-Order | |
| YSLY-CY-JZ | 4 x 35 | Cut-to-Order |
For other dimensions, please kindly submit required quantity for quotation.
